CAD Manager's Newsletter (#474)

11 Aug, 2021 By: Robert Green


CAD from Home, Part 1:
Workstations

If your CAD team needs to work from home — whether from COVID-19 restrictions or work/lifestyle changes — they must have the right workstation to get CAD work done.

Just when we thought it was safe to return to the office, the COVID-19 Delta variant has raised its head and now everyone is asking, “Are we going to continue working from home?” This is a question I’m hearing from more CAD managers these days as the fundamental business thinking has evolved to home-based work becoming more permanent than temporary, at least for the near-seeable future.

In this edition of the CAD Manager’s Newsletter, I’ll begin a periodic series on the concept of remote-from-home CAD from a CAD manager’s point of view. We’ll get the conversation started with workstations and what type of hardware you need in your home office. Here goes.

Image source: Pol Solé/stock.adobe.com, screenshots from Siemens NX Mold Designer.

Mobile Workstations vs Laptops

One question I’m asked quite a lot is, “What kind of laptops should I get for remote CAD workers?” I usually stop the conversation right there and insist that we no longer talk about laptops but mobile workstations instead.

Why the vocabulary lesson? Because, right from the start, I want to be sure upper management and companies understand that CAD work requires a workstation-level machine, not a cheap laptop. After all, if a BIM specialist must model a large building project, they need real workstation power — whether they’re at home or the office. The same holds true for someone designing mechanical assemblies, rendering, animating CAD geometry, performing analysis, or any other heavy-use scenario.

Conclusion 1: The era of cheap laptops has given way to the mobile workstation.



What about Desktop Machines for Home Workers?

Another statement I hear quite often is, “I can’t afford mobile workstations for everyone who works from home!” My reply is always that it is easy to ship a desktop machine to a user’s home office, rather than buying an entirely new mobile workstation. And, for that matter, desktop workstations don’t have to be huge towers either.

In my personal work, I’ve used HP Z Mini workstations to achieve workstation power in a compact format that can be easily shipped, thrown in a travel bag for trips to remote offices, or even mounted to the back of a monitor stand in the most crowded home offices. Other options are all-in-one–style computing devices in the form factor of a monitor such as the Dell OptiPlex. My point is that desktop machines don’t have to take up tons of room or dominate your home office.

Conclusion 2: Just because you work from home doesn’t mean you have to have a mobile workstation, there are numerous compact desktop options.



Peripherals Matter

I’ve been using a combination of mobile and desktop workstations at home for years and have travelled extensively with mobile devices. No matter where I am or go, I always take my trusty Logitech mobile keyboard and mouse with me and do everything I can to have a second monitor available.

What does this have to do with working from home? Good question. My point is that CAD users are generally used to full-sized keyboards, a particular style of mouse, perhaps a 3D space controller, and absolutely require a second monitor. At minimum, buy a 24” second monitor for mobile workstation users and dual monitors for desktop users. Most mobile workstations can accommodate these peripherals with on-board connectors but sometimes a docking station that supports more monitors or high-speed backup drives might be required.

 While we’re at it, don’t forget to provide home-based workers with a business class headset/mic device for Teams meetings. My go-to devices are my Yeti Blue microphone with high quality headphones for my desktop and a Logitech H800 headset for mobile applications.

 Conclusion 3: A productive work from home CAD environment isn’t just about the workstation.

Don't be penny wise and pound foolish! Find out why you shouldn't skimp on your teams' workstation setups. Plus, learn what each should have on their desk to get their work done well.


Read more»
