Today’s Hybrid CAD Office, Part 2

How to manage staffing, training, and workflows to keep your hybrid office working smoothly.

In the last installment of The CAD Manager’s Newsletter, we delved into the complex 2D/3D/BIM/Cloud world of the hybrid CAD office. We focused on the problems that arise in the hybrid environment and started a discussion on how to arrive at the ideal mixture of tools you’ll need. In this edition of the CAD Manager’s Newsletter, we’ll complete our discussion by looking at some specific workflow, staffing, and training strategies you can use to reduce complexity and lower costs in your hybrid CAD environment. Here goes.

Image source: vegefox.com/stock.adobe.com.

Figuring Out “The Right Blend”

I envision the hybrid CAD office as a blended environment where a wide range of tools and formats come together to form a workable CAD ecosystem. It sounds simple when you say it, but it can be hard to know what the right blend is. Let’s consider the following:

  • What’s 2D, 3D, or BIM? Which work processes are best accomplished with what types of tools?
  • What formats must you deliver? The actual file formats you deliver to your clients (DWG, RVT, DGN, etc.) may also inform what tools you must use to create your finished products. In some cases, the client may be a construction firm that wants PDF files. In another case, the “client” may be a laser cutter that requires DWG file input with all tooling paths implemented as polylines. From these two examples you can see how the output requirements may or may not dictate specific tools.
  • What’s on the Cloud? Will you use cloud-based applications, or regular CAD/BIM tools with the data stored in the Cloud? How will you manage the users and data synchronization required to keep everyone working on the same files?
  • Where are the interface points? Which tools must work together flawlessly to deliver the work? In some cases, BIM tools and 2D CAD tools must be integrated; in other cases, you may need to aggregate data from field instruments or scanned point clouds into CAD tools for design purposes. Knowing which tools you have to interface with is key.
  • What does it all cost? Of course, you’ll want to manage all these different tools at the lowest total cost over time and that will also inform which tools you will use.

It doesn’t sound easy, does it? It isn’t! In fact, it’s a complex equation with many variables that must be solved, so we need some additional constraints to arrive at a solution. Let’s explore how to arrive at the best blended hybrid environment possible.



WhatDoes the Staff Need?

CAD tools change, workstations change, and cloud architectures change, but the one thing that never changes is that your business is only as successful as your staff allows you to be. Or, put another way, you can buy all the hardware, software, and network tools you like, but without good people that are correctly deployed you’ll have nothing but problems. Here then, are some things to consider as you figure out the best blend for your hybrid CAD office.



Review Robert Green's list of what types of users need what software tools, be sure to set standards and train users, plus learn how to best handle data management.  Read more »
